15.6-inch 4K UltraHD 60Hz 3840-by-2160, FHD 60Hz 1920-by-1080 or FHD 120Hz 1920x1080 pixels

1/ World's first Intel Z370 based high performance NVIDIA 10 series MXM3 GPU- and CPU-upgradeable laptop with Coffee Lake 6cores/12treads LGA1151 socket based Processor
2/ Super fast 1GbE Killer E2500 LAN onboard
3/ Supports total 4 active displays at 4K 60Hz each
4/ Ports: 1 x Thunderbolt3 (USB 3.1c); 3 x USB 3.0 (1x powered, AC/DC); 1 x USB 2.0; 2 x mini DisplayPort 1.3; 1 x HDMI 2.0 output; 1 x 2-in-1 Audio Jack (Headphone / S/PDIF); 1 x Microphone-in; 1 x Line-out; 1 x Line-in; 1 x RJ-45 LAN; 1 x DC-in
5/ USB powered port for charging external devices without powering system on
6/ Supports total four drives, 2x PCIe x4 NVMe M.2 slots + 2x 2.5inch SATA3 for storage
7/ Prewired for 3G/4G/LTE internal module so you can just plug in internal M.2 3G/4G/LTE module and get Broadband Internet
8/ Built-in TPM 2.0 for maximum security
9/ GPU-upgradeable: MXM 3.1 slot; Nvidia GeForce GTX 1080, 1070 and 1060
10/ Unlocked BIOS with overclocking support for maximum performance with "K" series of Intel 8xxxK processors
11/ Designed like a racing car with easy access to all components for future expansion / upgrades
12/ Anti Ghosting backlit keyboard with easy to change colors and glow effects of your illuminated keys.
13/ High capacity SD UHS II card reader
14/ Dual high fidelity microphones with noise cancellation on the laptop lid for stereo studio quality recording.
15/ Sound Blaster X Pro-Gaming 360˚ and ESS SABRE HiFi DAC for high res headphone audio
16/ 7 high quality copper heat pipes covering the CPU and VGA array for shared thermal budget
ConfigureSpecificationsImagesPrice ListComponentsUser ManualDriversUpgradeUpgrade Price List
Launch Date:November 15, 2017
Special Feature(s):World's first 15.6-inch Coffee Lake CPU- and GPU-upgradeable laptop based on Intel Z370 Chipset and powered by 6core/12treads CPU and NVIDIA GeForce 1080/1070/1060 MXM 3.1
Main Chipset:Intel Z370 (Coffee Lake)
Processor:Socket LGA 1151
Coffee Lake CPUs; up to i7-8700K
Video / GPU:Modular MXM 3.1; 100x124mm; up to 190W
NVDIA GeForce GTX 1080, 1070 and 1060
supports GPU Overclocking
Built-in PC Camera:Built-in 2M FHD
Display:15.6in; eDP
FHD (1920x1080); 60Hz
FHD (1920x1080); 120Hz
4K UHD (3840x2160); 60Hz
up to 4 active displays; up to 4K @ 60Hz
Memory:Four 260-pin 1.2V SODIMM sockets;
DDR4-2133/2400/2666/3000; up to 64GB; non-ECC
Total Storage:up to 4 physical drives:
- 2x M.2 2280 SSD PCIe 2x/4x NVMe or SATA
- 2x 2.5" 9.5mm/7mm HDD/SSD/SHDD
- RAID 0/1
- supports Intel Optane technology
Optical Drive:External; USB based DVD-RW or Blu Ray-RW
Card Reader:6-in-1 Push-Push Card Reader
Audio Architecture:High Definition Audio; Realtek ALC892
S/PDIF Digital Output
Built in microphone
Built in two 2W speakers
7.1CH output (headphone, mic, line-in and S/PDIF)
ESS Sabre ES9018K2M HiFi Audio DAC (headphone)
Sound Blaster X Pro-Gaming 360°
LAN/WLAN/Bluetooth:- 1Gb Ethernet LAN on-board; Killer E2500
- WLAN / Bluetooth; M.2 2230 slot' supports 1Gbit WLAN
- prewired for 3G/4G/LTE (built-in antenna and SIM socket)
Data and Physical:Kensington Lock
TPM 2.0 on-board (Infineon SLB9665-TCG)
Internal cards / # of slots/Type:Four M.2 slots
-1st: WLAN M.2 2230 Card with PCIe x2
-2nd for SSD M.2 2280 Card with SATA / PCIe x2/x4 NVMe / Optane
-3rd for SSD M.2 2280 Card with SATA / PCie x2/x4 NVMe
-4th M.2 3042 for LTE or UMTS/HSPA
I/O Ports:1 x Thunderbolt3 (USB 3.1C)
1 x USB 3.1C
3 x USB 3.1 (1x powered, AC/DC)
1 x USB 2.0
2 x mini DisplayPort 1.3
1 x HDMI 2.0 output
1 x 2-in-1 Audio Jack (Headphone / S/PDIF)
1 x Microphone-in
1 x Line-out
1 x Line-in
1 x RJ-45 LAN
1 x DC-in
Internal Keyboard:Backlit (7-colours) full size keyboard with numeric pad
TouchPad with multi-gesture and scrolling
W/A/S/D Gaming key
AC Adapter:330W 100-240V 50-60Hz Auto-switching
Battery:8cells Smart Li-Ion; 82WH
up to 130 minutes
Weight:3.4kg/ 7.48 lbs w/ battery
Dimensions WxDxH:386x262x38mm; 15.44x10.48x1.52-inch
Shipping / Packaging L xWx H / N.W. / G.W.:547x112x319mm / 21.88x4.48x12.76 inch
5.48kg / 12lbs
