| Launch Date: | June 1, 2016 |
| Special Feature(s): | Built-in Smart Card Reader
Built-in ExpressCard 54/34 slot
Built-in Docking Station Port
|
| Main Chipset: | Mobile Intel® Q170 Express Chipset |
| Processor: | Socket LGA1151
Skylake Intel i7-6700T;i5-6600T, 6500T; HD Graphics 530
Kaby Lake; Intel i7-7700T; i5-7600T,7500T; HD Graphics 630 |
| Video / GPU: | Intel HD Graphics 530 (iGPU); Skylake
Intel HD Graphics 630 (iGPU); Kaby Lake
|
| Built-in PC Camera: | Built-in 1M HD Webcam |
| LCD Size: | 15.6in / 39.62cm |
| LCD Specifications: | 15.6" (39.62cm) LED backlit; eDP
FHD (1920x1080 @60Hz)
Supports up to 4 active displays |
| Memory: | Two 204-pin SODIMM sockets
DDR3L-1600, 1866, 2133; 1.35V
up to 32GB |
| Total Storage: | up to 3 physical drives:
- 1st HDD/SSD SATA3 6Gb/s (9.5mm)
- 2nd M.2 2280 PCIe 2x/4x or SATA3 SSD)
- 3rd HDD/SSD via ODD bay (9.5mm)
- Intel Rapid Start Technology
- Intel Smart Response Technology
- RAID 0/1 |
| Optical Drive: | - internal DVD or Blu Ray Burner; swappable with HDD/SSD
- Ultra Slim 9.5mm
|
| Card Reader: | 6-in-1 Push-Push Card Reader
MMC/RSMMC
SD/mini SD/SDHC/SDXC |
| Audio Architecture: | High Definition Audio
S/PDIF Digital Output
Built in microphone
Built in two 2W speakers
|
| LAN/WLAN/Bluetooth: | 1Gb Ethernet LAN on-board (Intel vPro I219)
M.2 2230 slot for WLAN/Bluetooth
M.2 3042 slot prewired for 3G/4G/LTE/UMTS/HSPA module (built-in SIM socket) |
| Security: | Kensington Lock
Fingerprint (EgisTec ES603)
TPM 2.0 on-board (Infineon SLB9665 TCG)
SmartCard Reader (Alcor Micro AU9560-GBS-GR) |
| ExpressCard Slot: | ExpressCard 54/34 slot (Intel 100/C230 chipset)
Docking Station port (hot plug / cold plug) |
| Internal cards / # of slots/Type: | Three M.2 card slots
-1st for WLAN M.2 2230
-2nd for SSD M.2 2280 SATA/PCIe x2/x4
-3rd for M.2 3042 LTE or UMTS/HSPA
|
| I/O Ports: | 3 x USB 3.0 (1x powered USB) via Intel 100/C230 chipset
1 x USB 2.0
1 x HDMI output
1 x VGA
1 x 2-in-1 Headphone & S/PDIF
1 x Microphone-in
1 x RJ-45 LAN
1 x DC-in
1 x Docking Station |
| Internal Keyboard: | Backlit (white) full size with numeric pad
TouchPad with multi-gesture and scrolling; 108x63mm |
| AC Adapter: | 65W 100-240V 50-60Hz Auto-switching (worldwide)
DC Output 19V, 3.42A |
| Battery: | 6-cells Smart Li-Ion; 62WH
up to 340 minutes in UMA mode |
| Weight: | 2.5kg / 5.5lbs |
| Dimensions WxDxH: | 382x259.5x32.95mm / 15.28x10.38x1.30-inch
|
| Thickness: | 32.95mm / 1.32" |
| Shipping / Packaging L xWx H / N.W. / G.W.: | 22x13x5 inch / 11lbs; 550x330x120mm / 5kg
|
