17.3-inch FHD 1920-by-1080 pixels IPS Matte; backlit LCD

World's first Intel Xeon based, 17.3" lightweight Mobile Server with integrated display, keyboard and built-in internal battery (UPS)! EUROCOM S7 Pro Mobile Server supports up to 20TB of storage with four SATA3 6Gb/s physical drives in RAID 0/1/5/10, up to 32GB of memory and is powered by Intel's line of XEON E3-1200 v3 series processors.

  • Operating Systems: Server 2012R2, Windows 7, Windows 8.1, Windows 10; Linux
  • Core Logic: Intel Z97 Express Chipset; PCI 2.0
  • Processor: 4-core/8 treads Intel XEON E3-1200 v3 series; up to E3-1281 v3; socket LGA1150
  • Memory: up to 32GB; DDR3-1333/1600/1866; four physical SODIMM sockets
  • Storage: up to 20TB of storage with four physical drives (2x M.2 + 2x 2.5"); SATA3 6Gb/s; additional storage available via eSATA drives - NVME M.2 Drives have limited support in Windows 7 -
  • Redundancy and Performance: RAID 0/1/5/10
  • Network:1GbE RJ-45 LAN on-board; Realtek RT8111G
  • I/O Ports: 4x USB 3.0; eSATA; 2x DP 1.2; HDMI 2.0; Headphone; Microphone; S/PDIF out; Line-in; RJ-45 / LAN
  • Security: Kensington Lock; Fingerprint; TPM 2.0 on-board (Infineon SLB9665-TCG)
  • Weight: 3.9kg/ 8.58 lbs w/ battery
  • Dimensions WxDxH: 418x282x16-38.7mm; 16.72x11.28x0.64-1.55-inch
